PLC Controlled Pneumatic Wave Pool with Hot-dip Galvanized Steel Structure and 10+ Wave Patterns

Pneumatic Wave Machine — Air-Pressure Wave Generator

The Pneumatic Wave Machine is the core equipment of a wave pool, operating on an air-pressure water-propulsion principle: a centrifugal blower and air compressor generate high-pressure airflow, which is released instantly through pipelines and controlled air valves to push pool water into continuous, natural waves. Compared with vacuum wave machines (tsunami waves), the pneumatic wave machine features a simpler structure, lower cost, lower energy consumption and easier maintenance — the most cost-effective choice for building a wave pool in small and medium-sized water parks and resort hotels.

Key Features

• Air-pressure propulsion delivers soft, natural waves with controllable rhythm for a comfortable, safe guest experience
• PLC intelligent control switches between 10+ wave patterns (diamond wave, roller wave, continuous wave, intermittent wave and more) at the touch of a button
• Three power options (45 / 55 / 75 kW) precisely match different pool areas with no wasted energy
• Modular design — standardized air chambers, blower and pipelines for a short installation cycle
• Energy-saving & low-noise — operating cost is only a fraction of vacuum wave systems for a faster return on investment

Technical Specifications

• Model Small: 45 kW — covers 500–700 m²/unit
• Model Medium: 55 kW — covers 700–900 m²/unit
• Model Large: 75 kW — covers approx. 1000 m²/unit
• Wave Height: 0.9–1.5 m
• Wave Patterns: 10+
• Wave Principle: Centrifugal blower + air compressor + air-valve pipelines (air-pressure type)
• Control: PLC intelligent control
• Pool Requirement: minimum 500 m² recommended; pool shape and wave height customizable to site

Materials & Craftsmanship

• Blower: high-performance centrifugal blower with stable airflow and long service life
• Air Compressor: branded compressor for sufficient, stable air supply
• Pipelines & Air Chambers: 304 stainless steel / galvanized carbon steel, anti-corrosion and chlorine-resistant
• Control System: electromagnetic control system + PLC, supporting remote debugging and wave-pattern programming

Safety Design

• Air-chamber pressure relief protection + under-voltage / overload / leakage protection
• Anti-slip pool floor in the wave zone, safety railings and lifeguard positions along the edge
• Fully compliant with GB 8408 / GB/T 18168 special-equipment standards, CE and ISO 9001 certified, SGS audited

Applications

• Wave pools in medium-sized water parks
• Resort hotels and hot-spring resort swimming pools
• Community / municipal recreation center pools
• Cultural tourism scenic areas and farm outdoor water zones

Service & Delivery

• Turnkey service: survey, layout design, production, installation & commissioning, operation training and after-sale in one stop
• Delivery time: 45 days standard, 60–75 days for customization
• Warranty: 2-year warranty + on-site installation supervision by our engineers

Why Choose Us

• Turnkey service, fast delivery and one-stop after-sale
• Since 1994, over 30 years of rich experience in water park design and manufacturing
• No.1 market share in China for water slides and wave machines, 1000+ projects delivered
• Exclusive equipment & service provider for Chimelong Water Park and Zhuhai Dream Water City
• Exported to 35+ countries worldwide
• Factory audited by SGS & Intertek; 30,000 m² manufacturing base + another 30,000 m² under construction
